型号意义： 如200ZD-A60，200：出口直径为200mm，Z：渣浆泵，D：单泵壳，A：叶轮叶片数。A为5片，B为4片，C为3片，F为6片，60：叶轮直径60cm
材 质：高铬合金耐磨材质
应用范围：用来输送含有固体颗粒的磨蚀性浆体，如选矿厂处理精矿和尾矿、电厂除灰渣、选煤厂输送煤泥和重介选煤，输送矿浆等。
ZJD（ZD）单泵壳渣浆泵参数表：
| 型号 | 配带最大功率P(KW) | 流量Q(m³/h) | 扬程H(m) | 转速n(r/min) | 最高效率η% | 汽蚀余量NPSH(m) | 最大粒径(mm) | 重量（kg) |
| 600D-A82 | 500 | 1664-5600 | 5.2-27.8 | 300-595 | 88.3 | 2.2 | 152 | 4900 |
| 300D-A60 | 400 | 580-2403 | 8.9-53 | 730-980 | 81.1 | 4.3 | 96 | 2790 |
| 200ZJD-B45 | 90 | 138-638 | 5.7-30.4 | 490-980 | 70.7 | 2.0 | 51 | 1750 |
| 150ZJD-A60 | 450 | 156-704 | 28.9-150 | 700-1480 | 78.1 | 2.1 | 39 | 1657 |
| 150D-B55 | 132 | 139-630 | 11.3-53.7 | 490-980 | 65.7 | 2.3 | 56 | 1540 |
| 150DG-A50 | 55 | 62-279 | 9.3-44.6 | 490-980 | 73.1 | 2.1 | 30 | 1470 |
| 150D-A40 | 132 | 122-503 | 11.2-65 | 700-1480 | 57.9 | 2.6 | 40 | 830 |
| 100D-A60 | 220 | 71-305 | 29-147 | 700-1480 | 58.7 | 2.4 | 18 | 890 |
| 100D-A45 | 90 | 47-228 | 14.8-83.5 | 700-1480 | 51.8 | 2.2 | 22 | 810 |
| 100D-A45B | 90 | 41-219 | 12-76 | 700-1480 | 53.6 | 2.4 | 24 | 800 |
| 100DG-B45C | 90 | 53-233 | 13-66.6 | 700-1480 | 70.4 | 3.6 | 26 | 1290 |
| 100D-B40 | 75 | 61-268 | 12-61 | 700-1480 | 58.7 | 1.7 | 29 | 620 |
| 100DG-B38CS | 90 | 40-171 | 18.5-91 | 700-1480 | 73.2 | 3.4 | 18 | 1420 |
| 100D-A35 | 75 | 77-323 | 8.8-46 | 700-1480 | 62.4 | 1.9 | 42 | 550 |
| 80D-A36 | 37 | 41-167 | 8.9-47 | 700-1480 | 62.4 | 1.5 | 16 | 480 |
| 65D-A40 | 55 | 34-159 | 12.2-63.2 | 700-1480 | 54.6 | 2.1 | 16 | 490 |
| 65D-A30 | 22 | 21-99 | 7.0-35.6 | 700-1480 | 45.1 | 2.2 | 19 | 260 |
| 50D-D40 | 30 | 16-76 | 9.5-51.7 | 700-1480 | 48.5 | 1.2 | 10 | 320 |
| 50D-A30 | 18.5 | 16-78 | 6.1-36.3 | 700-1480 | 42.5 | 0.8 | 16 | 210 |
| 40D-A25 | 45 | 16.8-75 | 13.7-88.6 | 1400-2950 | 53 | 2.6 | 9 | 185 |
| 40D-B20 | 15 | 7.9-37 | 10.7-57.7 | 1400-2930 | 38 | 0.9 | 7 | 160 |
| 25D-A25 | 4 | 4.7-20 | 3.3-21.6 | 700-1440 | 41.8 | 3.3 | 5 | 107 |
| 25D-A15 | 5.5 | 4.4-19.3 | 6.2-35 | 1390-2900 | 41.8 | 1.3 | 8 | 89 |
